Certified Galvanized U-Bolts for Industrial Use
Heavy-duty ISI-certified galvanized U-bolts ideal for MNRE projects, ULB infrastructure, and PWD-approved applications. Corrosion-resistant and BIS-compliant for secure mounting in solar, telecom, and industrial setups. Trusted by EPC contractors and government procurement bodies across India.
Galvanized U‑Bolt Dimensions & Specs
Galvanized U‑Bolt – heavy‑duty U‑shaped bolt with corrosion‑resistant zinc or hot‑dip galvanised finish. Available in M6 to M20 thread sizes, multiple pipe‑fit dimensions, long thread lengths and BIS/ISI‑ready standards. Ideal for secure clamping of pipes, structural support, anchoring & general industrial use.
Specifications – Galvanized U‑Bolt
Parameter | Specification |
| Material | Carbon steel, mild steel with galvanized finish (zinc plated or hot‑dip) |
| Thread Size | M6, M10, M12, M16, M20 (inch equivalents available) |
| Pipe Size Compatibility | ½″ to 12″ nominal bore pipes (approx. 15 mm–324 mm OD) |
| Between‑Legs Diameter | From ~28 mm (for ½″) up to ~343 mm (for 12″ standard) |
| U‑Depth (Inside Height) | Standard: ~48–210 mm; Extended: up to ~387 mm |
| Thread Length | Standard: ~30–50 mm; Extended versions up to ~95 mm |
| Tensile/Yield Strength | ~90,000 psi yield / 120,000 psi tensile typical for ≤13″; up to 133,000 psi tensile for larger sizes |
| Finish / Coating | Zinc plating or hot‑dip galvanizing for corrosion resistance |
| Certifications | ISI/BIS compliance possible; ISO/DIN/ANSI standards supported per request |
| Usage Applications | Pipe clamping, structural anchoring, industrial mounting, construction, general use |
Use Cases Across Industries & Projects
Tailored uses of the Galvanized U‑Bolt for government procurement, industrial infrastructure, and specialized engineering sectors—highlighting its corrosion resistance, load-bearing strength, and secure pipe and structural fastening across diverse professional environments.
Municipal & Government
- Securing street light poles and utility poles
- Mounting signage, traffic and road infrastructure
- Fastening pipes in municipal water supply and sewage systems
- Anchoring elements in PWD infrastructure and bridges
- Securing outdoor catenary and overhead systems commissioning
Commercial & Industrial
- Clamping pipelines and conduits in process plants
- Securing structural beams and steel framing
- Fastening HVAC ducting and mechanical equipment
- Mounting telecom masts and antenna installations
- Assembly of industrial machinery and support brackets
Special Use Case
- Marine and offshore installations exposed to salt air
- Agricultural equipment frames and irrigation pipelines
- Suspension components in transportation and trailer systems
- Cable tray and telecom tower cabling management
- Temporary and modular scaffolding or steel gantry setups
Use Cases Across Industries & Projects
Installation, maintenance, warranty, and service details for the Galvanized U‑Bolt support compliance-driven procurement, help technical teams assess performance requirements, and reassure EPC contractors and government buyers regarding quality and after-sales support.
Installation Guide
- Measuring inside diameter and height to match pipe/structural size
- Pre-install alignment & template marking for accurate bolt placement
- Proper torqueing of nuts to specification for load integrity
- Applying anti-seize or lubricant on threads where needed
- Ensuring correct washer and saddle plates installation
Maintenance & Services
- Regular inspection for galvanization wear or corrosion signs
- Re-torque nuts periodically as part of preventive maintenance
- Re-coating or replacing fasteners as required in coastal or wet environments
- Cleaning threaded areas and applying rust-inhibitor sprays
- Access to replacement parts and spares on demand
Warranty & Assurance
- Manufacturer guarantee on galvanized coating and tensile strength
- Certificates of material compliance (e.g. GB / DIN standards)
- Load‑rating documentation for design validation
- ISO 9001/ISO-certified manufacturing and QC processes
- Dedicated customer support and issue resolution channels
Snapshots to Success – Designs, Installations & Innovation
High-resolution visuals, schematics, and application photos of the Galvanized U‑Bolt let institutional buyers and specifiers evaluate size, form, fit, and surface finish—ensuring the right choice for professional installations and engineering projects.
FAQs – What Customers Ask Most !
Your detailed FAQ resource for Galvanized U‑Bolt answers high-intent queries related to performance, sizing, certification, installation, and procurement—trusted information tailored for B2B and institutional buyers seeking secure, durable fastening solutions.
What is a Galvanized U‑Bolt and what is it used for?
A Galvanized U‑Bolt is a U-shaped threaded fastener coated with zinc for corrosion resistance. It clamps pipes, beams, cables, or round profiles to a support structure across industrial and infrastructure applications.
What sizes of Galvanized U‑Bolt are available?
Galvanized U‑Bolts typically range from thread M6 to M20 (or ¼″ to ⅝″), and inner diameters covering nominal pipe sizes from ½″ up to 16″ or more to fit diverse project needs.
How is a Galvanized U‑Bolt measured accurately?
Key parameters include inside diameter (distance between legs), inside height (or depth), thread size and length. Measurement templates or vernier calipers ensure specs match installation requirements.
Is the Galvanized U‑Bolt corrosion-resistant for outdoor use?
Yes, the zinc-coating (zinc plate or hot-dip galvanized) provides strong rust protection, ensuring long-term performance even in humid, coastal, and outdoor infrastructure environments.
What load capacity can a Galvanized U‑Bolt support?
Load capacity depends on thread size, material grade and galvanizing. Typical grades offer high tensile strength compliant with DIN/ISO standards; manufacturers provide graded load data.
Can a Galvanized U‑Bolt meet government tender specifications?
Yes. These U‑Bolts can be ISI/BIS compliant and manufactured per DIN, ISO or ASTM standards, making them eligible for municipal/government infrastructure and EPC procurement.
How should a Galvanized U‑Bolt be installed for optimal performance?
Installation involves matching bolt size to pipe/beam, aligning via template, torquing nuts uniformly, and using appropriate washers and saddle plates for load distribution.
How long does the zinc coating on a Galvanized U‑Bolt last?
The lifespan depends on environmental exposure and thickness of galvanizing. Hot-dip galvanizing typically endures years of outdoor exposure; coastal audits may require re-coating intervals.
Are custom sizes or finishes available for a Galvanized U‑Bolt?
Yes. Most suppliers offer custom inner diameters, leg heights, thread lengths, and finishes—including hot‑dip and PVC or zinc plating—on request.
Where can I order Galvanized U‑Bolt for bulk or tender projects?
You can source Galvanized U‑Bolts from certified fastener manufacturers in India offering ISO‑certified production, bulk‑order capacity, technical support and certified documentation.
