Best High Mast Pole (12Mtr-30Mtr) Manufacturer in India
Triveni Solar is a leading manufacturer of High Mast Poles in India, offering hot dip galvanized poles ranging from 12 to 30 meters in height. Engineered with high-grade steel and precision welding, our high mast poles are built to withstand extreme weather, provide uniform illumination, and last for decades. Trusted by smart city projects, highways, stadiums, airports, and industrial complexes, Triveni’s poles offer unmatched durability, quick installation, and pan-India service support.
High Mast Pole | Wind Resistant | Rust Proof | Galvanized | Durable Light Support
Triveni Solar’s High Mast Poles (12Mtr–30Mtr) are designed for performance, longevity, and ease of use. From large-area lighting to industrial applications, our poles meet international engineering and safety standards.
Ideal for highways, flyovers, port terminals, parking areas, stadiums, and more — Triveni’s high mast poles come with integrated hoisting systems and customizable lighting arrangements for your specific needs.
Key Features of High Mast Pole (12Mtr–30Mtr)
- High-Grade Steel Construction: Made from Q235 or Q345 structural steel.
- Height Options: Available in 12m, 16m, 20m, 25m, and 30m options.
- Hot Dip Galvanized Finish: Zinc coating up to 80–100 microns to protect from corrosion.
- Wind Speed Resistance: Designed for up to 180 km/h wind loads (IS 875 Part 3 compliant).
- Winch Hoisting System: Manual or motorized lowering system for easy maintenance of luminaires.
- Modular Segments: Easy transportation and fast assembly with bolted sections.
- Foundation Ready: Delivered with base plate, bolts, and AutoCAD civil drawing layout.
- Certified Product: IS 875, ISO 9001:2015 & ISO 14001:2015 certified.
- Trusted Across India: Installed at airports, PSUs, government roads, and ports.
Additional Information of High Mast Pole
| Parameter | Specification |
| Pole Type | Galvanized Steel Pole (Different Shapes) |
| Height Range | 12m to 30m |
| Material | Q235 / Q345 Grade Steel |
| Galvanization | Hot Dip Galvanized (80–100 microns coating) |
| Section Configuration | 2–4 bolted segments for transport & installation |
| Wind Speed Resistance | Up to 180 km/h (as per IS 875 Part 3) |
| Base Plate Thickness | 20mm to 40mm |
| Top Diameter | 70mm to 130mm (approx.) |
| Bottom Diameter | 200mm to 460mm (approx.) |
| Hoisting System | Internal/External winch (Manual/Motorized) |
| Lighting Support | Luminaire ring/arms for 6–24 floodlights |
| Accessories | Cable entry, locking system, lighting arm mounts |
| Foundation Bolts | Provided with complete layout + AutoCAD drawings |
| Finish Options | Galvanized + Paint (Optional powder coat) |
Short Highlights of High Mast Pole (12Mtr–30Mtr)
- Height Options: From 12 meters to 30 meters
- Material: Q235 or Q345 Steel.).
- Finish: Hot Dip Galvanized with up to 100 microns.
- Wind Resistance: Tested and certified up to 180 km/h.
- Design: Modular, sturdy, easy to transport and install.
- Applications: Highways, stadiums, industrial yards, airports.
- Certifications: IS 875 (Part 3), ISO 9001, ISO 14001
- Manufacturer: Triveni Solar – India’s trusted high mast pole expert.
FAQs
Frequently Asked Questions About High Mast Pole (12Mtr-30Mtr)
We’ve answered the most common queries to help you understand the strength, lifespan, and real-world reliability of our products.
What are high mast poles used for?
High mast poles are used for large-area lighting—such as highways, airports, sports stadiums, ports, and industrial zones.
What materials are used in Triveni’s high mast poles?
We use Q235 or Q345 high-strength steel with hot dip galvanization for superior strength and rust resistance.
Are these poles wind-resistant?
Yes. Our poles are engineered to withstand wind speeds up to 180 km/h, tested per IS 875 (Part 3) standards..
Do you provide installation drawings and support?
Absolutely. We provide AutoCAD civil layout drawings, bolt templates, and on-site installation support (optional).
Do the poles include an internal hoisting system?
Yes, you can choose manual or motorized internal winch systems based on your requirement.
Are your poles compatible with LED lighting?
Yes. Our poles support various luminaire ring/arm options and are LED-ready.
Do the poles come with warranties?
Yes. All poles come with a 5-year manufacturing warranty, and lifetime rust-resistance if properly maintained.
How long does it take to manufacture and deliver?
Standard delivery timeline is 7–10 working days across India.
Can the poles be customized for special lighting configurations or heights?
Yes. We offer complete customization in terms of pole height, lighting arms, luminaire rings, and mounting accessories to match specific project requirements.
What maintenance is required for high mast poles?
Thanks to hot dip galvanization, our poles are low-maintenance. However, we recommend periodic inspection of the winch system, bolts, and lighting fixtures every 12–18 months.
