Best Semi Integrated Solar Street Light Manufacturer in India
Triveni Solar is the Best Semi Integrated Solar Street Light Manufacturer in India, which designs and manufactures durable, energy-efficient Semi Integrated Solar Street Lights tailored for municipal projects, gated communities, rural roads, industrial complexes, and institutional campuses. Combining high-efficiency solar panels with lithium battery packs and separate LED fixtures, these systems offer the ideal balance of performance, maintenance flexibility, and cost optimization. Built under ISO 9001:2015 standards with RoHS and MNRE alignment, Triveni’s products ensure powerful illumination with low environmental impact.
Semi Integrated Solar Street Lights – Smart, Modular & Long-Life Lighting Systems
Triveni’s Semi Integrated Solar Lights feature an external solar panel paired with a compact fixture that houses the battery and LED luminaire. This configuration enhances heat dissipation, simplifies component replacement, and allows panel orientation for improved solar efficiency. These systems support automatic dusk-to-dawn operation, motion detection, and advanced charging protocols for uninterrupted night lighting.
Key Features of Triveni Semi Integrated Street Lights
- High-efficiency mono/poly solar panels (separate from fixture)
- LiFePO₄ or lithium-ion battery integrated within LED unit
- LED module output: 12W to 40W with high-lumen intensity
- MPPT or PWM controller for optimized battery performance
- Weatherproof casing for LED fixture and solar module (IP65/IP67)
- Auto on/off and optional motion sensor dimming
- Rust-resistant GI, tubular or octagonal pole options
Additional Information of Semi Integrated Street Lights
| Parameter | Specification |
| Panel Type | Mono / Polycrystalline (12V / 24V) |
| Fixture Output | 12W / 15W / 20W / 30W / 40W LED |
| Battery Type | LiFePO₄ or Lithium-ion within fixture body |
| Battery Capacity | 12.8V / 18Ah to 24Ah (model-dependent) |
| Backup Duration | 10–12 hours with overcharge/discharge protection |
| Controller | MPPT or PWM (auto-regulating) |
| Sensor Support | PIR motion sensor for dimming (optional) |
| Fixture Mounting | Side arm / top bracket / dual mount |
| Pole Height | 3 m to 6 m (GI, octagonal, FRP-coated available) |
| Compliance | ISO 9001:2015 / MNRE / RoHS / BIS Certified |
Short Highlights of Semi Integrated Street Lights
- Modular design simplifies maintenance and upgrades
- Improved solar panel orientation for maximum energy harvesting
- Compact luminaire body with built-in battery
- Optional smart dimming for energy efficiency
- Ideal for rural, urban, institutional, and industrial lighting
- Tested for impact, corrosion, and thermal stability
- Bulk procurement and installation services PAN India
- Customized for municipal, CSR, and Smart City infrastructure
FAQs
Frequently Asked Questions About Triveni Semi Integrated Street Lights
We’ve answered the most common queries to help you understand the strength, lifespan, and real-world reliability of our products.
What is the difference between semi and fully integrated models?
Semi Integrated systems use an external panel and a separate luminaire with built-in battery, offering improved cooling and serviceability.
Are these suitable for outdoor applications?
Yes — fixtures and panels are built to withstand rain, dust, and heat with IP65/IP67 rated enclosures.
Can solar panel tilt be adjusted?
Since the panel is separate from the fixture, it can be angled independently for optimal solar exposure.
Do you offer motion sensor functionality?
Yes — optional PIR sensors allow dimming during inactivity, extending battery life and coverage.
Are batteries replaceable?
Lithium batteries are housed in the fixture body and can be replaced during servicing without removing the pole or panel.
What types of poles are compatible?
GI tubular, octagonal, and decorative poles from 3 m to 6 m height are offered with bracket options.
Can we customize branding on poles or fixtures?
Yes — Triveni offers lamination, decals, QR tags, and project coding for identification and branding.
Do these models support MNRE or tender requirements?
All models meet MNRE, RoHS, BIS, and ISO specifications required for government or civic projects.
What is the typical lifespan of components?
LED fixtures last up to 50,000 hours, batteries for 3–5 years, and solar panels over 20 years.
Is delivery and installation supported across India?
Yes — we provide PAN India supply, on-site installation, training, and servicing for street lighting projects.
