Best Tabular/Swaged Pole (3Mtr-12Mtr) Manufacturer in India
Triveni Solar is the best manufacturer in India of Tabular/Swaged Poles (3Mtr–12Mtr) . Triveni’s poles are cost-effective, high-strength lighting solutions built for durability and smart integration. Ideal for street, campus, industrial, and solar applications, they feature modular swaged joints, hot dip galvanization, and BIS-certified safety compliance. Easy to install, customizable, and engineered to perform in challenging outdoor environments.
Tabular Street Light Pole | Swaged GI/MS Poles | 3Mtr–12Mtr | BIS Certified | Hot Dip Galvanize
Triveni Solar’s Tabular/Swaged Poles (3Mtr–12Mtr) are cost-effective, high-strength lighting solutions built for durability and smart integration. Ideal for street, campus, industrial, and solar applications, they feature modular swaged joints, hot dip galvanization, and BIS-certified safety compliance. Easy to install, customizable, and engineered to perform in challenging outdoor environments.
Key Features of Tabular/Swaged Pole (3Mtr–12Mtr)
- Material Strength: Manufactured from S355 grade galvanized steel or mild steel, ensuring stability under lighting and environmental loads.
- Height Options: Offered in 3m to 12m ranges to suit low-, mid-, and high-mount applications for urban and industrial zones.
- Swaged Sectional Profile: Poles use multi-section swaged joints to improve tensile load and allow modular transport without compromising rigidity.
- Finish Options: Available in Hot Dip Galvanized (60–80 microns), Red Oxide Primer, or Powder-Coated finishes for weather resistance and city branding
- Mounting Compatibility: Ready for single/double-arm brackets, LED street lights, solar panels, CCTV, and motion sensors.
- Foundation Kit Supplied: Includes base plate, anchor bolts, nuts, and CAD civil layout drawings for precision installation.
- Wind Resistance Compliance: Designed to withstand wind speeds up to 130 km/h per IS 875 Part 3, suited for most regional zones.
Additional Information of Tabular/Swagged Pole
| Parameter | Specification |
| Pole Type | Swaged Tabular Pole |
| Height Range | 3m to 12m |
| Material | GI (S355), Mild Steel |
| Galvanization | Hot Dip (60–80 microns) / Red Oxide / Powder-Coated |
| Diameter Range | 50mm (Top) to 200mm (Bottom) |
| Swaged Sections | 2 to 4 segments depending on height |
| Wind Resistance | Up to 130 km/h |
| Mounts Supported | LED, Solar, CCTV, Sensor Brackets |
| Accessories | Arm brackets, cable routing, caps |
| Foundation Kit | Base plate, bolts, CAD drawing |
Short Highlights of Tabular/Swaged Pole (3Mtr–12Mtr)
- Modular Height Options – Ideal for streets, factories, campuses
- Weatherproof Finish – Long-lasting protection in all conditions
- Quick Setup Design – Pre-drilled base for seamless installation
- Smart Integration Ready – Supports solar panels and smart lights
- Color-Custom Coating – Powder coat available in RAL codes
- CAD-Backed Layouts – Civil foundation drawings included
- Zero Maintenance Lifecycle – Galvanization eliminates corrosion worries
- Budget-Friendly Build – Economical without compromising quality
FAQs
Frequently Asked Questions Tabular/Swaged Pole (3Mtr–12Mtr)
We’ve answered the most common queries to help you understand the strength, lifespan, and real-world reliability of our products.
What applications are Swaged Poles suitable for?
These poles are perfect for street lighting, solar systems, boundary lighting, and institutional use.
Are they customizable in height or diameter?
Yes, poles can be customized by height, diameter, and section length to suit project needs.
What are swaged sections?
Swaged sections involve tapering ends that fit into one another, creating a strong mechanical bond without welding.
Can poles be powder-coated in corporate colors?
Absolutely. We offer powder-coating in custom RAL shades to match branding or city color codes.
How many sections are used for 12m poles?
Typically, 3 to 4 sections are used, depending on structural and transport requirements.
Are these poles BIS-compliant?
Yes, all poles are manufactured in accordance with IS 2713 and IS 875 Part 3 standards.
Do you supply installation kits?
Yes. Every pole comes with anchor bolts, base plate, and AutoCAD foundation layout.
Are these compatible with solar lights and sensors?
They’re fully compatible with solar brackets, motion sensors, and IoT-ready lighting systems.
brackets.
Is red oxide or galvanized finish better?
Galvanized finish offers superior corrosion protection, while red oxide is a budget-friendly base coat.
Can poles be installed manually or require machinery?
Shorter poles (up to 6m) may be manually installed; taller options typically need light crane support.
